Product Picture Raman Rxn5 Process analyzer front view

Raman Rxn5 process analyzer

Turn-key process Raman analyzer for quantitative chemical composition measurements

KRXN5C
Loading price
Prices temporarily unavailable
Price on request
activating price
price: provide information
Product Picture Raman Rxn5fProcess analyzer front view
  • F
  • L
  • E
  • X
©Endress+Hauser

Raman Rxn5 analyzer

Raman Rxn5 analyzer

Specs at a glance

  • Laser wavelength

    532 nm

  • Spectral coverage

    150-3425 cm-1 (532 nm)

Field of application

The Raman Rxn5 process analyzer is an industry-leading, turn-key, laser-based analyzer powered by Kaiser Raman technology. It provides quantitative chemical composition measurements using Raman spectroscopy. The design of the Raman Rxn5 incorporates customer requirements for serviceability and hazard-area certification, provides a compact footprint, and minimizes utilities consumption. The high optical efficiency of the analyzer makes it ideal for typical gas-phase sample measurements.

Process measurement points:

  • Steam methane reformers

  • Gasifiers (coal, petcoke, waste, biomass)

  • Shift converters

  • Hydrotreaters

  • Hydrocrackers

  • CO2 removal

  • Finished product synthesis loops

Typical industries:

  • Hydrogen production/purity, HyCO, Hydrogen recycle,

  • Methanol production

  • Ammonia production

  • Gas turbine fuel feed

  • Synthetic natural gas/IGCC power plants

Benefits

  • Non-destructive analysis of gases, including homonuclear diatomics (H2, N2, O2)

  • Compact, smaller than most wall-mount gas chromatographs (GCs)

  • Can replace up to four traditional analyzers with a single base unit and four probes

  • Rugged with minimal utility requirements, no sample transport, and no consumables (columns, valves, gases, pumps)

  • Minimal analyzer technician time with maximum technician safety (no toxic gases are transported to the analyzer)

  • Measures four streams simultaneously for faster multi-channel results

  • -20 to +50 °C operating environment
